If you select the Fibre folder, information about ports and fabric switches appears in the table on
the right of the tree. The Fibre folder is available only if the storage system contains a fibre channel
adapter.
DescriptionItem
This icon indicates a fibre channel port.
CLX-Y
Port information list
DescriptionItem
Fibre channel port names.Port Name
The period of time between authentication sessions to the same port. If the previous
authentication session to a port failed, the next authentication session starts after the
specified period of time elapses. The unit is seconds.
Time out
If authentication fails for the number of times specified in Refusal Freq., connection to
the port fails. Refusal Intvl. shows the interval (in minutes) from when connection to a
port fails to when the next authentication session starts.
Refusal Intvl.
Number of times that authentication is allowed for connection to a port. If authentication
fails for the specified number of times, connection to the port fails.
Refusal Freq.
Fabric Switch information list
DescriptionItem
Fibre channel port name.Port Name
User name of the fabric switch.User Name
Mode of authentication between ports and fabric switches.Mode
• bidirectional: The authentication mode is mutual.
• unidirectional: The authentication mode is not mutual.
Indicates whether to perform authentication for the fabric switch.Authentication
• Enable: The fabric switch is a target of user authentication.
• Disable: The fabric switch is not a target of user authentication.
Authentication window (fibre port selected)
Remote Web Console secondary windows must be defined for use in advance. When you select
Modify from this window to make user authentication settings, other users or programs are prevented
from changing storage system settings. When you close the secondary window, Modify mode is
released. For more information on Remote Web Console secondary windows and Modify mode,
see the HP XP7 Remote Web Console User Guide.
On the menu bar, click Actions, Port/Host Group, then Authentication. The Authentication secondary
window opens.
426 LUN Manager GUI reference
