HPE FlexNetwork MSR3012 User Manual

28
Field
Description
Min/Max/Average positive jitter
Minimum/maximum/average positive jitter in milliseconds.
This field is available only for the path jitter operation.
Sum/Square-Sum positive jitter
Sum/square sum of the positive jitter.
This field is available only for the path jitter operation.
Negative jitter number
Number of negative jitter.
This field is available only for the path jitter operation.
Min/Max/Average negative jitter
Minimum/maximum/average negative jitter in milliseconds.
This field is available only for the path jitter operation.
Sum/Square-Sum negative jitter
Sum/square sum of the negative jitter.
This field is available only for the path jitter operation.
TTL TTL value in the received reply packet.
Hop IP IP address of the node that sent the reply packet.
Time Time when the NQA client received the reply packet.
display nqa statistics
Use display nqa statistics to display NQA operation statistics.
Syntax
display nqa statistics [ admin-name operation-tag ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
admin-name operation-tag: Specifies an NQA operation by its administrator name and operation tag.
The admin-name argument represents the name of the administrator who creates the NQA
operation. The operation-tag argument represents the operation tag. Each of the arguments is a
case-insensitive string of 1 to 32 characters that cannot contain hyphens (-). If you do not specify an
NQA operation, the command displays statistics for all NQA operations.
Usage guidelines
The statistics are generated after the NQA operation completes. If you execute the display nqa
statistics command before the operation completes, the statistics are displayed as all 0s.
If a reaction entry is configured, the command displays the monitoring results of the reaction entry in
the period specified by the statistics internal command. The result fields display hyphens (-) in one
of the following conditions:
•
The threshold type is average value.
•
The monitored performance metric is ICPIF or MOS for the voice operation.
The command is not available for the UDP tracert operation.
Examples
# Display the statistics for the TCP operation with administrator name admin and operation tag test.
