D Command table
Cmd. Sub cmd. Data Description
00 see p. 190 Send operating frequency for transceive
01 see p. 190 Send operating mode for transceive
02 see p. 191 Read band edge frequencies
03 see p. 190 Read operating frequency
04 see p. 190 Read operating mode
05 see p. 190 Send operating frequency
06 see p. 190 Send operating mode
07 Select VFO mode
00 Select VFO A
01 Select VFO B
A0 Equalize VFO A and VFO B
B0 Exchange MAIN and SUB Bands
D0 Select MAIN Band
D1 Select SUB Band
08 Select Memory mode
0001 to
0105
Select Memory channel
(0001=M-CH01to0099=M-CH99,
0100=1A,0101=1b,0102=2A,0103=2b,
0104=3A,0105=3b)
0106 Select Call channel
00 to 19 Select Satellite Memory channel
(00=SatelliteM-CH00to19=Satellite
M-CH19)
09 Memory write
0A Memory copy to VFO
0B Memory clear
0C Read offset frequency
0D Send offset frequency
0E 00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
03 ∂F scan start
12 Fine programmed scan start
13 Fine ∂F scan start
22 Memory scan start
23 Select memory scan start
24 Mode select scan start
A1 Set ∂F scan span ±5 kHz
A2 Set ∂F scan span ±10 kHz
A3 Set ∂F scan span ±20 kHz
A4 Set ∂F scan span ±50 kHz
A5 Set ∂F scan span ±100 kHz
A6 Set ∂F scan span ±500 kHz
A7 Set ∂F scan span ±1 MHz
B0 Set as non-select channel
B1 Set as select channel
( The previously set number by CI-V is set
after turning power ON, or “1” is selected
if no selection is performed.)
D0 Set scan resume OFF
D3 Set scan resume ON
0F Read Split function or duplex setting
(00=OFF,01=ON,11=DUP–,12=DUP+)
00 Set the Split function OFF
01 Set the Split function ON
10 Set simplex operation
11 Set DUP– operation
12 Set DUP+ operation
Cmd. Sub cmd. Data Description
10 00 Send/read the tuning step 10 Hz (1 Hz)
01 Send/read the tuning step 100 Hz
02 Send/read the tuning step 1 kHz
03 Send/read the tuning step 5 kHz
04 Send/read the tuning step 6.25 kHz
05 Send/read the tuning step 9 kHz
06 Send/read the tuning step 10 kHz
07 Send/read the tuning step 12.5 kHz
08 Send/read the tuning step 20 kHz
09 Send/read the tuning step 25 kHz
10 Send/read the tuning step 50 kHz
11 Send/read the tuning step 100 kHz
12 Send/read the tuning step 1 MHz (except
for HF/50 MHz band)
11 00 Send/read attenuator OFF
20 Send/read 20 dB attenuator
12 00 Send/read ANT1 selection
01 Send/read ANT2 selection
13 00 Announce operating frequency, operating
mode and S-meter level with voice syn-
thesizer
01 Announce operating frequency and S-
meter level with voice synthesizer
02 Announce operating mode with voice syn-
thesizer
14 01 0000 to
0255
Send/read [AF] position
(0000=max.CCW,0255=max.CW)
02 0000 to
0255
Send/read [RF/SQL] position (RF gain
level)
(0000=max.CCW,0255=11o’clock)
03 0000 to
0255
Send/read [RF/SQL] position (squelch
level)
(0000=11o’clock,0255=max.CW)
06 0000 to
0255
Send/read [NR] position
(0000=max.CCW,0255=max.CW)
07 0000 to
0255
Send/read inner [TWIN PBT] position
(0000=max.CCW,0128=center,
0255=max.CW)
08 0000 to
0255
Send/read outer [TWIN PBT] position
(0000=max.CCW,0128=center,
0255=max.CW)
09 0000 to
0255
Send/read [CW PITCH] position
(0000=max.CCW,0128=center,
0255=max.CW)
0A 0000 to
0255
Send/read [RF POWER] position
(0000=max.CCWto0255=max.CW)
0B 0000 to
0255
Send/read [MIC GAIN] position
(0000=max.CCWto0255=max.CW)
0C 0000 to
0255
Send/read[KEYSPEED]position
(0000=max.CCWto0255=max.CW)
0D 0000 to
0255
Send/read [NOTCH] position
(0000=max.CCW,0128=center,
0255=max.CW)
0E 0000 to
0255
Send/read COMP level
(0000=0to0255=10)
0F 0000 to
0255
Send/read Break-IN Delay setting
(0000=2.0dto0255=13.0d)
12 0000 to
0255
Send/read NB level
(0000=0%to0255=100%)
15 0000 to
0255
Send/read Monitor gain
(0000=0%to0255=100%)
16 0000 to
0255
Send/read VOX gain
(0000=0%to0255=100%)
17 0000 to
0255
Send/read Anti VOX gain
(0000=0%to0255=100%)
18 0000 to
0255
Send/read CONTRAST level
(0000=0%to0255=100%)
19 0000 to
0255
Send/read BRIGHT level
(0000=0%to0255=100%)
