Icom i9100 User Manual

19
197
SPECIFICATIONS
■ General
•Frequencycoverage : (unit:MHz)
Receive
0.030–60.000*
1
*
2
136.000–174.000*
1
*
2
420.000–480.000*
1
*
2
1240.000–1320.000
†
Transmit
1.800–1.999*
2
, 3.500–3.999*
2
,
5.33050*
3
, 5.34650*
3
, 5.36650*
3
,
5.37150*
3
, 5.40350*
3
,
7.000–7.300*
2
, 10.100–10.150*
2
,
14.000–14.350*
2
, 18.068–18.168*
2
,
21.000–21.450*
2
, 24.890–24.990*
2
,
28.000–29.700*
2
, 50.000–54.000*
2
144.000–148.000*
2
, 430.000–450.000*
2
1240.000–1300.000
†
*
1
Some frequency bands are not guaranteed.
*
2
Depending on version. *
3
USA version only.
•Mode : USB,LSB,CW,RTTY,AM,FM,
DV*
*The optional UT-121 is required.
•No.ofmemorychannels : 297CH(99CH × 3 band)
(
396CH with UX-9100
‡
;99CH ×
4 bands)
•No.ofscanedge
memory channels : 18CH
(6 × 3 band)
( 24CH with UX-9100
‡
;6CH × 4
bands
)
•No.ofcallchannels : 3CH
(1 × 3 band)
( 4CH with UX-9100
‡
;1CH × 4
bands
)
•No.ofSatellite
memory channels : 20CH
•Antennaconnector :SO-239× 3
Type-N × 2
•Antenna impedance :
50 ø (at Antenna Tuner OFF)
• Usable temperature range : 0˚C to +50˚C (+32˚F to +122˚F)
•Frequencystability : Lessthan±0.5ppm5min.after
power ON.
(0˚Cto+50˚C;+32˚Fto
+122˚F)
•Frequencyresolution :1Hz
•Powersupply :
13.8VDC±15%(negative ground)
•Powerconsumption
Transmit
Max. power : 24.0 A
(HF/50/144/430 MHz band)
9.0 A
(1200 MHz band)
†
Receive
Standby : 3.0 A
(HF/50/144/430 MHz band)
4.0 A
(1200 MHz band)
†
Max. audio : 4.5 A (HF/50/144/430 MHz band)
5.5 A
(1200 MHz band)
†
•Dimensions : 315(W) × 116(H) × 343(D) mm
(projections not included) 12.4(W) × 4.57(H) × 13.5(D) in
•Weight(approximately) :11.0kg;24.2lb
11.95kg;26.3lb
(with UX-9100)
•ACCconnector : 13-pin
•CI-Vconnector : 2-conductor3.5(d)mm(
1
⁄8″)
■ Transmitter
•Outputpower(continuously adjustable)
Frequency band Output power
HF/50 MHz 2 to 100 W (AM: 2 to 30 W)*
144 MHz 2 to 100 W
430 MHz 2 to 75 W
1200 MHz
†
1 to 10 W
(at 13.8 V DC/+25˚C)
* In the AM mode, transmission can be performed only on
the HF/50 MHz frequency band.
•Modulationsystem
SSB : Digital PSN modulation
AM : Digital Low power modulation
FM : Digital Phase modulation
DV* :
GMSK Digital Phase modulation
*The optional UT-121 is required.
•Spuriousemission
(Spurious domain)
HF bands : Less than –50 dB
50/144 MHz band : Less than –63 dB
430 MHz band : Less than –61.8 dB
1200 MHz band
†
: Less than –53 dB
(Out-of-band domain)
HF bands : Less than –40 dB
50/144/430 MHz band : Less than –60 dB
1200 MHz band
†
: Less than –50 dB
•Carriersuppression : Morethan40dB
•Unwantedsideband
suppression : More than 55 dB
(1200 MHz: More than 40 dB)
†
•∂TX variable range : ±9.999 kHz
•Microphoneconnector : 8-pinconnector
•Microphoneimpedance : 600ø
•ELEC-KEYconnector :
3-conductor 6.35(d) mm (
1
⁄4″)
•KEYconnector :
3-conductor 6.35(d) mm (
1
⁄4″)
•SENDconnector : Phonojack
(RCA)
•ALCconnector : Phonojack(RCA)
†
The optional UX-9100 is required for 1200 MHz frequency band
operation.
‡
Only when the 1200 MHz frequency band is selected.
