INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-106-
Function
code
Name
Description
Default
30: Rotational speed (0–Twice the
motor rated synchronous speed)
31: Output torque
32: PID1 output
33: PID2 output
34: PID1 reference value
35: PID1 feedback value
36: PID2 reference value
37: PID2 feedback value
38–47: Reserved
P06.17
AO1 output lower limit
-300.0%–P06.19
0.0%
P06.18
AO1 output corresponding to
lower limit
0.00V–10.00V
0.00V
P06.19
AO1 output upper limit
P06.17–300.0%
100.0%
P06.20
AO1 output corresponding to
upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22
AO0 output lower limit
-300.0%– P06.23
0.0%
P06.23
AO0 output corresponding to
lower limit
0.00V–10.00V
0.00V
P06.24
AO0 output upper limit
P06.35–300.0%
100.0%
P06.25
AO0 output corresponding to
upper limit
0.00V–10.00V
10.00V
P06.26
AO0 output filter time
0.000s–10.000s
0.000s
P06.27–
P06.31
Reserved
5.5.11 Digital input
The VFD carries four programmable digital input terminals and two HDI input terminals. The function
of all the digital input terminals can be programmed through function codes. HDI input terminal can be
set to act as high-speed pulse input terminal or common digital input terminal; if it is set to act as a
high-speed pulse input terminal, you can also set HDIA high-speed pulse input to serve as the
frequency reference and encoder signal input.
