INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-187-
Function
code
Name
Description
Default
Modify
on the control board needs to be shorted.
P05.51–
P05.52
Reserved
P05.53
Keypad analog
lower limit
0.00V–P05.54
0.00V
○
P05.54
Corresponding
setting of
keypad analog
lower limit
-300.0%–300.0%
0.0%
○
P05.55
Keypad analog
upper limit
P05.56–10.00V
10.00V
○
P05.56
Corresponding
setting of
keypad analog
upper limit
-300.0%–300.0%
100.0%
○
P05.57
Keypad analog
input filter time
0.000s–10.000s
0.030s
○
P06 group—Output terminals
Function
code
Name
Description
Default
Modify
P06.00
Reserved
P06.01
Y1 output
0: Invalid
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
0
○
P06.02
Reserved
0
○
P06.03
RO1 output
1
○
P06.04
RO2 output
5
○
