INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Expansion card
-316-
Field
Field description
Naming example
Remarks
Product code
(I/O card)
01: Multiple-function I/O card
02: Multiple-function I/O card (with the
temperature detection function)
03: Reserved
Product code
(IC card)
01: GPRS card
02: 4G card
03: Reserved
⑤
Working power
00: Passive (Empty by default)
05: 5V
12: 12–15V
24: 24V
If multiple voltage classes
are supported, the highest
class is marked. For
example, EC-PG305-12
supports 5V and 12V.
⑥
Version description
Used to distinguish the
hardware/structure.
A: Standard version (Empty by default)
B: B version
The following table describes expansion cards that the VFD supports. The expansion cards are
optional and need to be purchased separately.
Name
Model
Specifications
I/O expansion card
EC-IO501-00
● 4 digital inputs
● 1 digital output
● 1 analog input
● 1 analog output
● 2 relay outputs: 1 double-contact output, and 1
single-contact output
EC-IO503-00
● 2 digital inputs and 6 relay outputs
PROFIBUS-DP
communication card
EC-TX503D
● Supporting the PROFIBUS-DP protocol
CAN multi-protocol
communication card
EC-TX505C
● Based on the CAN2.0A physical layer
● Supporting the CANopen protocol
PROFINET
communication card
EC-TX509C
● Supporting the PROFINET protocol
A.2 Dimensions and installation
All expansion cards are of the same dimensions (108x39mm) and can be installed in the same way.
All the VFD models provide two expansion card slots. Note the following when installing or
uninstalling an expansion card:
