INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Installation guidelines
-29-
4.3.2 Main circuit terminal diagram
8.8
10.0
8.5
11.5
57.5
Figure 4-20 Main circuit terminal for 3PH 380V 1.5–7.5kW (unit: mm)
12.5
14.5
116
Figure 4-21 Main circuit terminal for 3PH 380V 11–15kW (unit: mm)
14
136
17
Figure 4-22 Main circuit terminal for 3PH 380V 18.5–22kW (unit: mm)
