Goodrive270 series VFD for fan and pump Function parameter list
-207-
Function
code
Name
Description
Default
Modify
P08.56
Temperature point
of carrier frequency
reduction
40.0–80.0°C
65.0°C
â—‹
P08.57
Wait time of carrier
frequency reduction
0–30min
10
â—‹
P08.58
Output phase loss
detection delay
during running
0.0–360.0s
Note: When the run time exceeds the delay, the
VFD detects for output phase loss.
5.0s
â—‹
P09 group––PID control
Function
code
Name
Description
Default
Modify
P09.00
PID reference
source
When frequency command selection (P00.06,
P00. 07) is 7, or channel of voltage setup
(P04.27) is 6, the running mode of VFD is
process PID control.
The function code determines the target given
channel during the PID process.
0: Set by P09.01
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: Multi-step running
6: Modbus communication
7: PROFIBUS/CANopen communication
8: Ethernet communication
9: Reserved
10: PROFINET communication
The set target of process PID is a relative value,
for which 100% equals 100% of the feedback
signal of the controlled system.
The system always performs calculation by
using a relative value (0–100.0%).
0
â—‹
P09.01
PID digital setting
The function code is mandatory when P09.00=0.
The base value of The function code is the
feedback of the system.
Setting range: -100.0%–100.0%
0.0%
â—‹
