INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Optional peripheral accessories
-354-
VFD model
Input reactor
Output reactor
GD270-185-4(-L1)
ACL2-200-4
(ACL2-160-4)
OCL2-200-4
GD270-200-4(-L1)
ACL2-200-4
OCL2-200-4
GD270-220-4(-Ln)
ACL2-280-4
/
GD270-250-4(-Ln)
ACL2-280-4
/
GD270-280-4(-Ln)
ACL2-280-4
/
GD270-315-4(-Ln)
ACL2-350-4
/
GD270-355-4(-Ln)
ACL2-350-4
/
GD270-400-4-Ln
ACL2-400-4
/
GD270-450-4-Ln
ACL2-500-4
/
GD270-500-4-Ln
ACL2-500-4
/
Note:
 The rated input voltage drop of input reactor is designed to 2%.
 The rated output voltage drop of output reactor is designed to 1%.
 The preceding table lists only external accessories. You need to specify whether external or
built-in accessories are needed in your purchase order.
 If output reactors need to be configured for 220kW and higher VFDs, choose the L3 models.
 n = 1 or 3
D.7 Filters
D.7.1 Input filters
D.7.1.1 SCHAFFNER input filters
For 30–132kW models, you can choose the GD270 standard models and configure external
SCHAFFNER FN3258/FN3359 series filters to meet the IEC/EN 61800-3 First environment (C2)
EMC requirements under the condition of 20m motor cable. Table D-6 lists the filter model selection.
For more details about the SCHAFFNER filters, please contact us.
