INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-233-
Function
code
Name
Description
Default
Modify
expansion card in
card slot 2
The value 0.0 indicates that identification fault
will not be detected.
P16.26
Time to identify
expansion card in
card slot 3
0.0–600.0s
The value 0.0 indicates that identification fault
will not be detected.
0.0s
○
P16.27
Communication
timeout period of
card at slot 1
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.28
Communication
timeout period of
card at slot 2
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.29
Communication
timeout period of
card at slot 3
0.0–600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s
○
P16.30–
P16.69
See the operation manual of communication expansion card for details
P17 group––Status viewing
Function
code
Name
Description
Default
Modify
P17.00
Set frequency
Displays the present set frequency of the VFD.
Range: 0.00Hz–P00.03
50.00Hz
●
P17.01
Output frequency
Displays the present output frequency of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp reference
frequency
Displays the present ramp reference frequency
of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Displays the present output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output current
Displays the valid value of current output current
of the VFD.
Range: 0.0–5000.0A
0.0A
●
P17.05
Motor rotation
speed
Displays the current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque current
Displays the present torque current of the VFD.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting current
Displays the present exciting current of the VFD.
0.0A
●

INVT Goodrive270 Series Specifications

General

Control Mode	V/F control, Sensorless vector control
IP Rating	IP20
Cooling Method	Air cooling
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Overload, Short circuit
Communication	RS485, Modbus
Application	Water pump
Input Frequency	50Hz/60Hz
Output Voltage	0~Rated Voltage
Rated Current	Depends on the model
Operating Temperature	-10°C to +40°C
Storage Temperature	-20°C to 60°C
Humidity	<95% (non-condensing)
Altitude	Below 1000m
