INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Optional peripheral accessories
-357-
VFD model
Input filter
GD270-315-4(-Ln)
FLT-P04800L-B
GD270-355-4(-Ln)
GD270-400-4-Ln
GD270-450-4-Ln
FLT-P041000L-B
GD270-500-4-Ln
Note: n = 1 or 3
D.7.2 Output filters
Choose the filters in the following table to meet the C2 EMC requirements under the condition of 1m
motor cable.
Table D-8 Output filter model selection for AC 3PH 380V VFDs
VFD model
Output filter
GD270-1R5-4(-C2)
FLT-L04006L-B
GD270-2R2-4(-C2)
GD270-004-4(-C2)
FLT-L04016L-B
GD270-5R5-4(-C2)
FLT-L04032L-B
GD270-7R5-4(-C2)
GD270-011-4(-L1/-C2)
FLT-L04045L-B
GD270-015-4(-L1/-C2)
GD270-018-4(-L1/-C2)
FLT-L04065L-B
GD270-022-4(-L1/-C2)
GD270-030-4(-L1)(-C3)
FLT-L04065L-B
GD270-037-4(-L1)(-C3)
FLT-L04100L-B
GD270-045-4(-L1)(-C3)
GD270-055-4(-L1)(-C3)
FLT-L04150L-B
GD270-075-4(-L1)(-C3)
GD270-090-4(-L1)(-C3)
FLT-L04240L-B
GD270-110-4(-L1)(-C3)
GD270-132-4(-L1)(-C3)
GD270-160-4(-L1)
FLT-L04400L-B
GD270-185-4(-L1)
GD270-200-4(-L1)
GD270-220-4(-Ln)
FLT-L04600L-B
GD270-250-4(-Ln)
GD270-280-4(-Ln)
GD270-315-4(-Ln)
FLT-L04800L-B
GD270-355-4(-Ln)
