FRONT AXLE
M6040, M7040Narrow, WSM
N6-S3
(2) Disassembling Front Axle Case
Shutter Plate
NOTE
• When remove the differential gear, remove the shutter
plate.
1. Remove the screw (2).
2. Remove the shutter plate (1).
(When reassembling)
• Set the shutter plate as much as wider.
IMPORTANT
• Do not remove the shutter plate screw (2), unless
necessary.
• The screw (2) is not for the drain plug, check port plug and
filling port plug.
9Y1210220FAS0004US0
(1) Shutter Plate (2) Screw
KiSC issued 07, 2012 A

Kubota M6040 NARROW Specifications

General

Engine Type	Diesel
Hydraulic System	Open Center
Wheelbase	203.5 cm
Fuel Type	Diesel
Drive	4WD
Fuel Capacity	66 L
3-Point Hitch	Category II
Type	Tractor
Displacement	2.4 L
Fuel Tank Capacity	66 L
Transmission	8-speed synchro-shuttle
