TRANSMISSION
M6040, M7040Narrow, WSM
N3-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" at "NG. GENERAL" Section.)
9Y1210220TRS0002US0
Item N·m kgf·m lbf·ft
Brake pipe retaining nut 15.7 to 23.5 1.6 to 2.4 11.6 to 17.4
Engine and clutch housing mounting screw and nut
(M14, 7T)
124 to 147 12.6 to 15.0 91.2 to 108
Transmission case and clutch housing mounting screw
and nut (M10, 9T)
60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Transmission case and clutch housing mounting screw
and nut (M14, 9T)
166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
KiSC issued 07, 2012 A

Kubota M6040 NARROW Specifications

General

Engine Type	Diesel
Hydraulic System	Open Center
Wheelbase	203.5 cm
Fuel Type	Diesel
Drive	4WD
Fuel Capacity	66 L
3-Point Hitch	Category II
Type	Tractor
Displacement	2.4 L
Fuel Tank Capacity	66 L
Transmission	8-speed synchro-shuttle
