Kubota M6040 NARROW User Manual

CABIN
M6040, M7040Narrow, WSM
N10-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" at "NG. GENERAL" section.)
9Y1210220CAS0002US0
Item N·m kgf·m lbf·ft
Front wheel mounting nut 259.9 to 304.0 26.5 to 31.0 191.7 to 224.2
Rear wheel mounting nut 259.9 to 304.0 26.5 to 31.0 191.7 to 224.2
Outer roof mounting screw 3.5 to 4.0 0.36 to 0.40 2.6 to 2.9
Cabin mounting bolt and nut (M14, 9T) 124 to 147 12.6 to 15.0 91.2 to 108
Cabin mounting bolt and nut (M12, 7T) 77.5 to 90.2 7.9 to 9.2 57.2 to 66.5
High pressure hose and low pressure hose mounting
screw
7.95 to 11.7 0.80 to 1.19 5.86 to 8.67
Compressor bracket mounting screw (M8) to aluminum
parts
17.7 to 20.5 1.8 to 2.1 13.1 to 15.1
Compressor bracket mounting screw (M8) to
ordinariness parts
23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Compressor bracket mounting screw (M10) to ordiness
parts
48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
A/C unit mounting screw (M6) 4.0 to 6.8 0.40 to 0.70 2.9 to 5.0
A/C unit mounting screw (M8) 9.81 to 11.6 1.00 to 1.19 7.24 to 8.60
Low pressure pipe (Cooler pipe (suction)) retaining nut 30 to 34 3.0 to 3.5 22 to 25
High pressure pipe (Cooler pipe (liquid)) retaining nut 12 to 14 1.2 to 1.5 8.7 to 10
High pressure pipe 1 mounting screw (Compressor
side)
7.95 to 11.7 0.80 to 1.20 5.86 to 8.67
High pressure side 1 retaining nut (Condenser side) 20 to 24 2.0 to 2.5 15 to 18
High pressure pipe 2 retaining nut (Receiver side) 12 to 14 1.2 to 1.5 8.7 to 10
Low pressure pipe mounting screw (Compressor side) 7.95 to 11.7 0.80 to 1.20 5.86 to 8.67
High pressure pipe 2 retaining nut 12 to 14 1.2 to 1.5 8.7 to 10
Low pressure pipe retaining nut 30 to 34 3.0 to 3.5 22 to 25
Wiper motor mounting nut 6.4 to 9.3 0.65 to 0.95 4.7 to 6.8
Hose clamp screw 48.1 to 55.9 4.9 to 5.7 35.5 to 41.2
Steering joint shaft screw 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Drain plug 196.2 to 225.5 20.0 to 23.0 144.7 to 166.3
KiSC issued 07, 2012 A

Kubota M6040 NARROW Specifications

General

Engine Type	Diesel
Hydraulic System	Open Center
Wheelbase	203.5 cm
Fuel Type	Diesel
Drive	4WD
Fuel Capacity	66 L
3-Point Hitch	Category II
Type	Tractor
Displacement	2.4 L
Fuel Tank Capacity	66 L
Transmission	8-speed synchro-shuttle
