HYDRAULIC SYSTEM
M6040, M7040Narrow, WSM
N8-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" at "NG. GENERAL" section.)
9Y1210220HYS0002US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.8 to 224.2
Sprocket nut (M16, 9T) 260 to 304 26.5 to 31.0 191.8 to 224.2
Relief valve assembly 34.3 to 39.2 3.5 to 4.0 25.3 to 28.9
3-point hitch delivery pipe retaining nut 107.9 to 117.7 11.0 to 12.0 79.6 to 86.8
Rear ROPS mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 191.8 to 224.2
Cylinder hose retaining nut 45.1 to 53.0 4.6 to 5.4 33.3 to 39.1
3-point hitch hydraulic block mounting screw 166.7 to 196.1 17.0 to 20.0 123.0 to 144.7
3-point hitch hydraulic block mounting nut 123.6 to 147.1 12.6 to 15.0 91.1 to 108.5
