HYDRAULIC SYSTEM
M6040, M7040Narrow, WSM
N8-S1
1. SERVICING SPECIFICATIONS
POSITION AND DRAFT CONTROL LINKAGE
9Y1210220HYS0001US0
Item Factory Specification Allowable Limit
Position Control Rod (ROPS Model) Length Approx.
180 mm
7.09 in.
–
Draft Control Rod (ROPS Model) Length Approx.
170 mm
6.69 in.
–
Position Control Rod (CABIN Model) Length Approx.
262 mm
10.31 in.
–
Draft Control Rod (CABIN Model) Length Approx.
235 mm
9.25 in.
–
Position Feedback Rod Length 156 mm
6.14 in.
–
Draft Feedback Rod Length 252 mm
9.92 in.
–
