Kubota M6040 NARROW User Manual

TRANSMISSION
M6040, M7040Narrow, WSM
N3-S4
(2) CABIN Model
Checking Function of Main Gear Shift
1. Check the function of the main gear shift.
• Neutral position to 1st gear position.
• Neutral position to 2nd gear position.
• Neutral position to 3rd gear position.
• Neutral position to 4th gear position.
• Neutral position to 5th gear position.
2. If shifting is not smooth, check the length of main shift rod (1).
The select cable (2) are fixed at the center of thread.
9Y1210220TRS0004US0
Length of select shift rod
"L"
Factory specification
655 mm
25.8 in.
(1) Main Shift Rod
(2) Select Cable
L : Select Shift Rod Length
KiSC issued 07, 2012 A

Kubota M6040 NARROW Specifications

General

Engine Type	Diesel
Hydraulic System	Open Center
Wheelbase	203.5 cm
Fuel Type	Diesel
Drive	4WD
Fuel Capacity	66 L
3-Point Hitch	Category II
Type	Tractor
Displacement	2.4 L
Fuel Tank Capacity	66 L
Transmission	8-speed synchro-shuttle
