Lenze ECS series User Manual

Commissioning
Setting of the feedback system for position and speed control
TTL/SinCos encoder as position and speed encoder
6

117
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
409 AM256−8V
(
mu
lti
−
t
urn
)
Selections 407, 408, 409 are only
possible with operating system
7.0 or higher.
410 AM512−8V
411 AM1024−8V
[C0420] Encoder const. 512
Number of increments of the
encoder
 331
 115
 122
1 {1 inc/rev} 8192 Sets C0419 = 0 ("common") if the
value is altered.
[C0421] Encoder volt 0
Encoder voltage
 331
 115
 122
0 5.0 V
Sets C0419 = 0 ("common") if the
value is altered.
1 5.6 V
2 6.3 V
3 6.9 V
4 7.5 V
5 8.1 V
[C0427] Enc. signal 0
Function of the master frequency
input signals on X8 (DFIN)
 331
 115
 122
0 2−phase
1 A: speed
B: direction
2 A or B: speed or direction
[C0491] X8 in/out 0
Function of X8
 331
 115
 122
0 X8 is input
1 X8 is output
