13.15.10 TRIP status (DCTRL_bExternalFault_b)
If "TRIP" is activated in the drive (e.g. via the variable DCTRL_bTripSet_b, C0135/bit 10 or
keypad), the variable DCTRL_bExternalFault_b is set to TRUE.
DCTRL_bExternalFault_b is reset to FALSE, as soon as the error source is reset.
13.15.11 Transfer of the status/control word via AIF
If the control and/or status word of the SB DCTRL_DriveControl is to be assigned to the
SB Inputs_AIF1/Outputs_AIF1, this can be realised in the IEC 1131−3 programming
language AWL, e. g. as follows:
LD DCTRL_wStat
ST AIF1_wDctrlStat /* Writing the status word*/
LD AIF1_wDctrlCtrl
ST DCTRL_wAIF1Ctrl /* Writing the control word*/
 Note!
The assignment of the bits of the control/status word marked as "not
assigned" depends on the fieldbus module used and the transmission profile
set (z. B. DRIVECOM).
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0135 Control word 0
System control word DCTRL
0 {1} 65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0 Not assigned
Bit 1 Not assigned
Bit 2 Not assigned
Bit 3 Quick stop (QSP)
Bit 4 Not assigned
Bit 5 Not assigned
Bit 6 Not assigned
Bit 7 Not assigned
Bit 8 Operation inhibit (DISABLE)
Bit 9 Controller inhibit (CINH)
Bit 10 TRIP−SET
Bit 11 TRIP−RESET
Bit 12 Not assigned
Bit 13 Not assigned
Bit 14 Not assigned
Bit 15 Not assigned
