Lenze ECS series User Manual

System modules
DCTRL_DriveControl (node number 121)
Outputs_DCTRL
13

323
EDBCSXA064 EN 3.2
13.15.2 Outputs_DCTRL
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Notes
DCTRL_wCAN1Ctrl
Word
˘
%QW121.3
˘ ˘
CAN control word
DCTRL_wAIF1Ctrl %QW121.2 Control word AIF
DCTRL_bCInh1_b
BOOL binary
%QX121.0.1 C0878/1
bin
Controller inhibit
( 325)
DCTRL_bCInh2_b %QX121.0.2 C0878/2
DCTRL_bTripSet_b %QX121.0.3 C0878/3 TRIP SET ( 326)
DCTRL_bTripReset_b %QX121.0.4 C0878/4 TRIP RESET ( 326)
DCTRL_bStatB0_b
BOOL binary
%QX121.1.0
˘ ˘ Status signals ( 327)
DCTRL_bStatB2_b %QX121.1.2
DCTRL_bStatB3_b %QX121.1.3
DCTRL_bStatB4_b %QX121.1.4
DCTRL_bStatB5_b %QX121.1.5
DCTRL_bStatB14_b %QX121.1.14
DCTRL_bStatB15_b %QX121.1.15
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0135 Control word 0
System control word DCTRL
0 {1} 65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0 Not assigned
Bit 1 Not assigned
Bit 2 Not assigned
Bit 3 Quick stop (QSP)
Bit 4 Not assigned
Bit 5 Not assigned
Bit 6 Not assigned
Bit 7 Not assigned
Bit 8 Operation inhibit (DISABLE)
Bit 9 Controller inhibit (CINH)
Bit 10 TRIP−SET
Bit 11 TRIP−RESET
Bit 12 Not assigned
Bit 13 Not assigned
Bit 14 Not assigned
Bit 15 Not assigned
