DCTRL_DriveControl (node number 121)
Inputs_DCTRL
13

322
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0136 Control words
Hexadecimal value is bit−coded.
Read only
1 CTRLWORD
0 {hex} FFFF
Control word C0135
2 CTRLWORD CAN control word
3 CTRLWORD AIF control word
C0150 Status word 0
Device status word 1 (DCTRL)
Read only
 328
 327
0 {1} 65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0 Not assigned DCTRL_bStateB0_b
Bit 1 Pulse inhibit (IMP) DCTRL_bImp_b
Bit2 Not assigned DCTRL_bStateB2_b
Bit3 Not assigned DCTRL_bStateB3_b
Bit4 Not assigned DCTRL_bStateB4_b
Bit5 Not assigned DCTRL_bStateB5_b
Bit 6 n = 0 DCTRL_bNActEq0_b
Bit 7 Controller inhibit (CINH) DCTRL_bCInh_b
Bit 8 Device status bit 1 DCTRL_bStat1_b
Bit 9 Device status bit 2 DCTRL_bStat2_b
Bit10 Device status bit 3 DCTRL_bStat4_b
Bit11 Device status bit 4 DCTRL_bStat8_b
Bit12 Warning DCTRL_bWarn_b
Bit13 Message DCTRL_bMess_b
Bit14 Not assigned DCTRL_bStateB14_b
Bit15 Not assigned DCTRL_bStateB15_b
C0878 Digital input signals to DCTRL
Only display
 321
1 DigInOfDCTRL 0 1 Controller inhibit (CINH) 1
2 DigInOfDCTRL Controller inhibit (CINH) 2
3 DigInOfDCTRL TRIP−set
4 DigInOfDCTRL TRIP−RESET
