Lenze ECS series User Manual

Appendix
Memories
Retain memory
14

376
EDBCSXA064 EN 3.2
14.3 Memories
The table below gives you an overview of the memories available:
Memory Size Information
ROM
Program memory
512 kbytes Re−written whenever the program is downloaded
RAM
PLC data memory 10 kbytes Can be symbolically used for FB instances and PLC variables.
Application memory 2 blocks
à 64 kbytes
Data get lost after mains disconnection.
E2PROM−buffered memory
Retain memory 160 bytes See chapter 14.3.1
Persistent memory 32 bytes See chapter 14.3.2
 Tip!
Function library LenzeMemDrv.lib includes functions for read/write access to
the additional backup memory (application data memory) of the ECSxA... axis
module.
 Further information ...
can be found in the Manual for the function library LenzeMemDrv.lib.
14.3.1 Retain memory
The values of the retain variables are stored fail−safe in the retain memory, and therefore
are still available to the program after mains switching. Saving with C0003 = 1 is not
necessary.
ƒ Retain variables are declared by using the variable class VAR RETAIN.
ƒ Retain variables are created as a symbolically addressable memory.
ƒ At every program download, the retain variables are reset to their initialisation
value; if no initialisation value is specified, the respective retain variable is initialised
with the value ’0’.
ƒ The retain variables in the ECSxA... axis module can be reset to their initialisation
value in the online mode of the DDS by using the commands Online
Reset (cold) or
Online
Reset (original).
