Lenze ECS series User Manual

System modules
AIF_IO_Management (node number 161)
Outputs_AIF_Management
13

258
EDBCSXA064 EN 3.2
13.1.2 Outputs_AIF_Management
This SB serves to transfer command and messages to a fieldbus module connected to an
automation interface (AIF).
For this purpose, a control word is available via C2120. The commands are given as
numbers. Some command numbers generally apply to all fieldbus modules, others only
apply to single fieldbus modules. A total of 16 commands can be made available.
 Please read the documentation for the connected fieldbus module.
Bit 7
Toggle-Bit (MSB)
Bit8…15
AIF control word
Outputs_AIF_Management
AIF_wControl
C2120
Bit0…6
ECSXA243
Fig. 13−2 System block "Outputs_AIF_Management"
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Notes
AIF_wControl Word ˘ %QX161.0 C2120 ˘
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C2120 AIF: Control 0
AIF−CAN: control word
 258
0 {1} 255 Binary interpretation reflects bit
states
0 No command
Note: The MSB (bit 7) of the
control word automatically
changes its state with every
access to the code. Observe this
when interpreting the data!
1 Read XCAN codes + reinitialisation
2 Read XCAN code
10 Read XCAN C2356/1 ... 4
11 Read XCAN C2357
12 Read XCAN C2375
13 Read XCAN C2376 ... C2378
14 Read XCAN C2382
255 Not assigned
