Lenze ECS series User Manual

Monitoring functions
Configuring monitoring functions
Monitoring times for process data input objects
10

203
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2457 Monitoring time for
CANaux1...3_IN (CAN bus
interface X14)
 202
1 CE monit time 3000 1 {1 ms} 65000 CE11 monitoring time
2 CE monit time 3000 CE12 monitoring time
3 CE monit time 3000 CE13 monitoring time
The following responses can be set for communication errors:
ƒ 0 = Error (TRIP) − controller sets controller inhibit (CINH)
ƒ 2 = Warning
ƒ 3 = Monitoring is switched off
Codes for setting the response to the monitoring functions:
CAN bus interface Code Monitoring
X4
ECSxS/P/M: MotionBus (CAN)
ECSxA: System bus (CAN)
C0591 CAN1_IN ("CE1")
C0592 CAN2_IN ("CE2")
C0593 CAN3_IN ("CE3")
C0595 Bus off ("CE4")
C0603 Gateway function ("CE5")
X14
System bus (CAN)
C2481 CANaux1_IN ("CE11")
C2482 CANaux2_IN ("CE12")
C2483 CANaux3_IN ("CE13")
C2484 Bus off ("CE14")
C2485 Gateway function ("CE15")
The input signals (CAN1...3_IN/CANaux1...3_IN) can also be used as binary output signals,
e.g. for the assignment of the output terminal.
Bus off
If the controller disconnects from the CAN bus due to faulty telegrams, the signal
"BusOffState" (CE4/CE14) is set.
"BusOffState" can activate an error (TRIP) or warning. The signal can also be switched off.
The response is set under C0595/C2484. You can also assign the terminal output for this.
