Appendix
Table of attributes
14
439
EDBCSXA064 EN 3.2
Access
Data
Index
Code
Condition
LCM−R/W
Decimal
position
DL
Format
DT
DA
DS
hex
dec
Code
C2483
22092
564Ch
E
1
FIX32
VD
4
0
Ra/Wa
C2484
22091
564Bh
E
1
FIX32
VD
4
0
Ra/Wa
C2485
22090
564Ah
E
1
FIX32
VD
4
0
Ra/Wa
C2491
22084
5644h
A
6
B16
VH
2
0
Ra
C2492
22083
5643h
A
11
FIX32
VD
4
2
Ra
C2493
22082
5642h
A
11
FIX32
VD
4
2
Ra
C2500
22075
563Bh
A
255
FIX32
VD
4
0
Ra/Wa
C2501
22074
563Ah
A
255
FIX32
VD
4
0
Ra/Wa
438
