Technical data
Current characteristics
Increased continuous current depending on the control factor
3
45
EDBCSXA064 EN 3.2
The following table shows the connections between mains voltage, DC−bus voltage and
motor voltage:
Mains voltage
[U
mains
]
DC−bus voltage
[U
DC
= U
mains
x 1.35]
Output voltage (motor voltage)
nominally achievable for 100 %
modulation
[U
mot
= 0.66 x U
DC
]
3 x 230 V AC 310 V DC 3 x 205 V AC
3 x 380 V AC 510 V DC 3 x 340 V AC
3 x 400 V AC 540 V DC 3 x 360 V AC
3 x 415 V AC 560 V DC 3 x 370 V AC
3 x 460 V AC 620 V DC 3 x 415 V AC
3 x 480 V AC 650 V DC 3 x 435 V AC
3 x 528 V AC 712 V DC 3 x 475 V AC
For steady−state operation in generator mode with increased DC−bus voltage or supply
from a closed−loop DC−voltage source, interpolate accordingly between the values given in
the table.
The increased rated currents are valid for the entire voltage range specified at switching
frequencies of 4 kHz and 8 kHz.
Note!
If in this connection a heatsink temperature of > 70 °C is reached, the drive
switches to a switching frequency of 4 kHz, independently of the selected
switching frequency.
