Mindray TE5 User Manual

Image Optimization 5-43
MPR Viewing
In the actual display, different colors for the window box and the section line are used to identify
the MPR A, B and C.
 Window A is blue, and the lines (representing MPR A) displayed in the other two windows
are also blue.
 Window B is yellow, and the lines (representing MPR B) displayed in the other two
windows are also yellow.
 Window C is orange, and the lines (representing MPR C) displayed in the other two
windows are also orange.
The positions of the other two MPRs are indicated in the selected plane by color described above.
Display Format
Tap to select the display format of VR and MPR images: [Single], [Quad] and [A4:1].
MPR Only
Tap [MPR Only] to display MPR only. The adjustable image parameters are changed to MPR
parameters automatically.
Only A, B and C MPR are displayed, and VR is not displayed.
Sectional A
Sectional B
Sectional C
