Annotations and Body Marks 9-5
9.2.3 Voice Comment Review
Open a cine file with voice comment, and during the cine review mode, voice comments are played as
well.
For details about opening a cine file, please see Chapter 6 Display & Cine Review.
9.3 Body Mark
The Body Mark (Pictogram) feature is used to indicate the patient's position during the exam as
well as the transducer position and orientation.
The system supports body marks for Abdomen, Cardiology, GYN, OB, Urology, Small Part and
Vascular applications.
9.3.1 Adding Body Marks
1. Select [Annotate] -> [Body Markers] on the operating panel to enter Body Mark status as well
as open the body marker menu.
2. Tap to select the desired body mark to bring out the Position Probe Marker dialogue box.
3. To adjust the probe position and orientation marker:
Tap and rotate the bold solid green line to position the probe marker.
Tap and rotate the dotted line to adjust the probe marker orientation.
4. Tap [Set] to confirm the position and orientation of the probe marker and add the mark.
9.3.2 Moving Body Marks
You can move the body mark graphics to any desired position within the image area.
1. Tap to select the body mark. The body mark is covered by a green frame, indicating you can
move it to a new position.
2. Tap the desired position to place the body mark.
In Dual-split mode, a body mark cannot be moved between the separate image
windows.
9.3.3 Deleting Body Marks
Tap [Clear Markers] to delete the added body mark.
