Exam Preparation 4-7
3. Enter the search condition:
Set query criteria from Patient ID, Patient Name, MRN, Scheduled Station AE Title,
Worklist Server, Modality Type or Exam Date. Or select the search key, enter the
keywords, then tap [Query] to search.
To reset the criteria, tap [Clear].
4. Select the desired patient record in the displayed patient list.
5. Select the desired patient and tap [Done]. The patient information is imported into the system
and then an exam is started.
4.2 Select Exam Mode and Probe
If the exam mode is changed during a measurement, all measurement
calipers on the image will be cleared. The general measurement data will
be lost, but application measurement data will be stored in the reports.
Selecting exam mode
1. Tap [Probe] on the left side of the operating panel. The screen displays the following dialog box:
2. Tap to select the probe model and exam mode. The system exits the dialog box and enters the
selected exam mode and probe.
To Next Page
