Image Optimization 5-1
5 Image Optimization
The images displayed in this system are for
reference only. Mindray is not responsible for the
correctness of diagnostic results.
Tissue Harmonic Imaging does not use contrast
agents.
5.1 Imaging Mode
5.1.1 Switching Between Imaging Modes
On the operating panel, tap imaging mode buttons on the right to switch the mode.
Current imaging mode is indicated by highlighting the button in blue. For instance, the above
status shows that the system is under B+Color+PW mode (triplex is turned on).
5.1.2 Image Adjustment
1. Tap [Image] on the operating panel to open the image parameter control menu under different
imaging modes.
2. Swipe the menu downwards/upwards to check and change parameter controls.
