Mindray TE5 User Manual

3-8 System Preparation
3.7 Installing a Graph/Text Printer
 Connecting a local printer
NOTE:
Printers listed in “2.3.4 Peripherals Supported” chapter have drivers installed already.
As shown in the figure below, a graph / text printer has a power cord and data cable. The
power cord should be directly plugged into a well-grounded outlet.
1. Connect the data cable to the USB port on the ultrasound system.
2. Power the system and the printer on.
3. Put the installation optical disk of the printer driver into the external DVD R/W drive.
4. Install the printer driver: Select [Setup] -> [System] -> [Peripheral] -> [Add Printer].
5. Select [Add a local printer] and tap [Next] to enter the screen used for browsing driver.
Data cable
USB port
Power supply
cable
