Image Optimization 5-9
Echo Boost
This function can improve contrast and decrease noise, so that a much clearer
boundary can be seen.
Set [Echo Boost] to be “On” to turn the function on.
This function is only available using the phased probe in cardiac exam mode
(probe P7-3Ts does not support this function)
Patient Temperature
If the current active probe is P7-3Ts, the parameter will display under the B mode
menu. You can enter the patient temperature by this function.
Enter the temperature by tapping [Patient Temperature].
If the patient temperature is above 37°C (98.6° F) and the [Patient
Temperature] setting is below the actual reading, the system could
overestimate the temperature of TEE transducer’s distal tip. This
could trigger the Auto-Cool feature. If the patient temperature
reaches or is near 37°C (98.6°F) and the [Patient Temperature]
setting is above the actual reading, the system could underestimate
the temperature of the TEE transducer's distal tip. The patient is
exposed to excessive temperatures.
Middle Line
“Middle Line” helps to locate the focus point of shock wave during the treatment.
By watching the treatment procedure in real-time and adjusting the intension and
frequency of the shock wave, the harm to the patients can be reduced to the
least.
Tap [Middle Line] on the image menu to hide or display the line.
Dual Live
Display different image effects of one probe for a better observation.
Tap [Dual Live] to turn on/off the function, and dual-split window of images are
displayed on the main screen.
Two pages of adjustable parameters are displayed; where, shared parameters
and left window parameters are displayed in the B(L) page, while right window
parameters are displayed in the B(R) page.
In the image parameter area on the top-left corner of the main screen,
parameters of the both windows are displayed.
Image magnification is available in dual live mode.
