Mindray TE5 User Manual

Barcode Reader C-3
C.1.2 Setting Up the Reader (taking LS2208 as an example)
1. Plug the interface cable modular connector into the cable interface port on the bottom of the reader
handle and ensure the connector is properly secured.
2. Connect the other end of the interface cable to the host.
1.
Cable interface port
2.
Interface cable modular connector
C.1.3 Setting
The reader has factory settings. See A.4 for details.
The reader supports some user-defined functions as described below.
For more details, contact the SYMBOL reader agent or the Mindray Customer Service Department.
 Volume setting:
Scan the following barcode to set the volume parameter.
 Code 93 and codebar scanning:
To enable or disable Code 93, scan the appropriate barcode below.
To enable Codebar, scan the appropriate barcode below.
