Configure Switching
108
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
10. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
Configure GARP Switch Settings
The Generic Attribute Registration Protocol (GARP) is used to exchange information
between GARP participants to register and deregister attribute values within a bridged LAN.
When a GARP participant declares or withdraws a given attribute, the attribute value is
recorded with the applicant state machine for that attribute, for the port from which the
declaration or withdrawal was made.
• Registration occurs only on ports that receive the GARP PDU containing a declaration or
withdrawal.
• Deregistration occurs only if all GARP participants connected to the same LAN segment
as the port withdraw the declaration.
GARP is part of the IEEE 802.1p extension to its 802.1D (spanning tree) specification. It
includes the following:
• GARP Information Declaration (GID). The part of GARP that generates data.
• GARP Information Propagation (GIP). The part of GARP that distributes data.
Note: It can take up to 10 seconds for GARP configuration changes to take
effect.
 To configure GARP switch settings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switchingï€ > VLAN > Advanced > GARP Switch Configuration.
