Monitor the System
309
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
View Port Statistics
The Port Statistics page displays a summary of per-port traffic statistics on the switch.
 To view port statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Monitoring > Ports > Port Statistics.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to the broadcast address, including those that were discarded or not
sent.
Address Entries in Use The number of learned and static entries in the Forwarding Database Address
Table for this switch.
Maximum VLAN Entries The maximum number of VLANs allowed on this switch.
Static VLAN Entries The number of active VLAN entries on this switch that were created statically.
Table 64. Switch statistics information (continued)
Field Description
