Manage Device Security
267
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
7. From the Private VLAN Type menu, select the type of private VLAN. Possible values are
as follows:
• Unconfigured. Sets the private VLAN type as unconfigured. This is the default
selection.
• Primary. Sets the private VLAN type as primary, which allows Layer 2 connectivity
from promiscuous ports to isolated ports and to community ports.
• Isolated. Sets the private VLAN type as isolated, which allows isolated ports to send
traffic to the primary VLAN and to promiscuous ports.
• Community. Sets the private VLAN type as community, which allows Layer 2
connectivity from community ports to promiscuous ports and to community ports of
the same community.
8. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
Configure Private VLAN Association Settings
 To configure private VLAN association:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > Traffic Control > Private Vlan > Private Vlan Association
Configuration.
6. From the Primary VLAN menu, select the primary VLAN ID of the domain.
You can select only a VLAN that you previously configured as a primary VLAN (see
Configure the Private VLAN Type on page 266).
