9 Cement
the vinyl
sheet
onto the door
inner
panel.
10
Refit
the tÍim strip,
the upholstery
panel
and the door
opening
handle.
11 Install the window
lifter
handle by turning
it towards
the
front
and slanting
it approximately 45 deg. down-
wards.
12:7 Replacing window
lifter
and cable assembly,
404 Cabriolet
1
Remove
the
glass panel
as detailed
in
Section
12:6.
2
Remove
the wrndow liÍter.
3 Slacken the
cable tensioner
(see
inset to FIG 12
:10),
located
on the
lower
pulley
bar.
To
gain
access to the
tensioner screw, remove the
rubber
plug
Írom
the
bottom of
the door. Remove the
cable.
4
Check
that all four
pulleys
rotate
freely
(see
item
2 of
FIG 12:10).
5 Fit the new wrndow
lrfter
and engage the cable on the
four
pulleys
in
succession
as
shown
in
FIG 12:10.
The section oÍ the cable,
item 4,
should
be
in Íront
of
the other
cable
sectrons
6 Turn the tensioner scÍew as
required
to obtain
moderate
tension on the cable.
7 Adjust the
position
of the
lower
pulley
bar by
slackening the attachment screws, item 3, to
prevent
the cable runs
Írom rubbing
against each other.
8
Insert the
glass panel
in the slides and check that the
panel
does
not
bind,
then lower it fully.
9 Turn
the window lifter crank Íully back, and then
rotate it Íorward
by
two turns.
10 lnstall both cable clamos with the crank
in
this
position,
and
tighten the
cable clamp screws.
1'1
Install
and
adjust
the window stops as detailed
in
Section
12 :6.
12
Check
for correct operation and lubricate the window
lifter mechanism.
13
Raise the
window
and
install
the trim
strip,
upholstery
panel,
door opening handle and window
liÍter
crank.
This should
be
turned towards the
front
and slanted
45
deg. downwards,
FIG
12
:10
Details oÍ cable
assembly
for window
lift
Key to Fig 12:10
i
Cable
tensioner 2 Pulleys 3
Lowet
pulley
bar screws 4 Cable
P404
FIG
12:11
Details
Key to Fig 12 : 11
2 Lower attachment nut
1
Uooer
attachment
screws
FIG 12:12 Ventilator adjustment
Keyto Fig 12:12
3
Outeredgeofrubbergaskel
4 Inner edge of rubber
gasket
1.09
