4.2
INSTALLATION PROCEDURE
NOTE:
To install th
is sorter on th
e A172/A
199 cop
ier, the A52
7 sorter
adapte
r kit (o
ption) is
neces
sary.
1. Remove four
pieces of tape:
Sorter Top Cover [A] (1 pc)
Transport
Guide [B] (2 p
cs)
Sorter Harness [C] (1pc)
2. Open th
e top cove
r [D] and remo
ve the fo
llowing items
:
Tape [E] (1 pc)
Cushion [F] (4 pcs)
Clam
p [G]
(1 pc)
[1 sc
rew]
Cardbo
ard [H] (1 pc)
[A]
[H]
[B]
[F]
[C]
[D]
[E]
[F]
[G]
[F]
A172/A199
3-38
SM
126
