15.14
FEED-IN MOTOR REPLACEMENT
1.
Turn of
f the
main swit
ch an
d remov
e the
upper c
over. (Re
fer to
Upper
Cover Removal.)
2.
Remov
e t
he fee
d-in mo
tor b
racke
t [A
] (3 s
crews)
, mak
ing s
ure no
t to
damage th
e timing belt.
3. R
emove the dr
ive pulle
y [B] (1 A
llen screw),
then repla
ce the fe
ed-in
motor [C]
(4 screws).
[A]
[B]
[C]
A172/A199
7-42
SM
362
