3.4.2
S
ystem ROM c
heck
sum test
Test Count:
4444
End
Testing ...
Check Address :
44444444
System ROM Check Sum Test
Diagnostic test (title)
[End] key.
Pressing this key
terminates the test
(for the continuous mode).
Number of times the system repeats the test
(for the continuous mode)
Message indicating that the test is
currently under way
A172/A199
6-38
SM
302
304
