1. INSTALLATION REQUIREMENTS
1.1 ENVIRONMENT
1. Temperature Range: 10°C to 32°C (50°F to 89°F)
2. Humidity Range: 15% to 90% RH
3. Ambient Illumination: Less than 2,000 lux (Do not expose to direct
sunlight.)
4. Ventilation: Minimum space 20 m
3
.
Room air should turn over at least
30 m
3
/hr/person
5. Ambient Dust: Less than 0.15 mg/m
3
(4 x 10
-6
, 4 x 10
-6
, Oz/yd
3
)
6. If the place of installation is air-conditioned or heated, do not place the
machine
a) where it will be subjected to sudden temperature changes,
b) where it will be directly exposed to cool air from an air conditioner,
c) where it will be directly exposed to heat from a heater.
7. Do not place the machine where it will be exposed to corrosive gasses.
8. Do not install the machine at any location over 2,000 m (6,500 feet)
above sea level.
9. Place the copier on a strong and level base.
10. Do not place the machine where it may be subjected to strong vibrations.
1.2 MACHINE LEVEL
1. Front to back: Within 5 mm (0.2") of level
2. Right to left: Within 5 mm (0.2") of level
NOTE: The machine legs may be screwed up or down in order to level
the machine. Set a carpenter’s level on the exposure glass when
you do this.
Installation
SM 3-1 A172/A199
