9.
A172/A199 Fiery XJ System Printer
γ
Adjustment Procedure
9.1 Procedure
After you install the Interface Kit Type-C in the A172/A199 copiers,
perform the following printer
γ
adjustment procedure.
NOTE: 1
The printer gamma must be adjusted for both Fiery print mode
settings (contone and halftone).
NOTE: 2
The ACC procedure automatically adjusts both printer gamma
settings (contone and halftone) at once. These printers modes can
not be adjusted independently using ACC.
1. Connect the copier to the Fiery XJ with the cable provided.
2. Turn on the copier. When the copier is in standing by mode, turn on the
Fiery XJ.
NOTE:
Make sure that the copier is not in use and that the Fiery XJ screen
displays "idle".
3. Print a Test Page to check the color balance and image density.
1) At the idle screen, press the menu button of the Fiery XJ LCD once.
2) Press the line selection button (to the right of "Print XJ Pages").
3) Select Test Page from the submenu to print the Test Page (default:
contone).
4. Compare the color scales on the Test Page just printed with the color
scales on the reference Fiery XJ Test Page.
Check that the various grades along the color scales are similar in
density to those on the reference Test Page.
5. If the color scales on the Test Page are not acceptable, perform the Auto
Color Calibration (ACC: Steps from 6 to 14).
Replacement
and
Adjustment
SM 5-29 A172/A199
To Next Page
