1.2.11 Output Check Mode Table
NOTE: • Output numbers written in bold italic letters with an asterisk
("*") are newly added items to the base copier (A109).
• Underlined output number items are the same as the base copier
but with a different output number (A109).
NOTE: The motors keep turning in this mode regardless of the upper or
lower limit sensor signal. Do not keep the electrical component
on for a long time, to prevent mechanical or electrical damage.
Output No. Electrical Component
1
Charge corona with grid - Bk
2
Charge corona with grid - C
3
Charge corona with grid - M
4
Charge corona with grid - Y
5
Development bias - Bk
6
Development bias - C
7
Development bias - M
8
Development bias - Y
9*
Transfer belt bias - 1C
10
*
Transfer belt bias - 2C / 1st color
11*
Transfer belt bias - 2C / 2nd color
12*
Transfer belt bias - 3C / 1st color
13
*
Transfer belt bias - 3C / 2nd color
14
*
Transfer belt bias - 3C / 3rd color
15
Transfer belt bias - 4C / 1st color
16
Transfer belt bias - 4C / 2nd color
17
Transfer belt bias - 4C / 3rd color
18
Transfer belt bias - 4C / 4th color
19*
Transfer belt bias (Back side) - 1C
20*
Transfer belt bias (Back side) - 2C / 1st color
21*
Transfer belt bias (Back side) - 2C / 2nd color
22*
Transfer belt bias (Back side) - 3C / 1st color
23*
Transfer belt bias (Back side) - 3C / 2nd color
24
*
Transfer belt bias (Back side) - 3C / 3rd color
25*
Transfer belt bias (Back side) - 4C / 1st color
26
*
Transfer belt bias (Back side) - 4C / 2nd color
27
*
Transfer belt bias (Back side) - 4C / 3rd color
28
*
Transfer belt bias (Back side) - 4C / 4th color
29
PCC
30
Drum cleaning bias (BR)
31
Transfer roller bias - Normal paper - 1C
32
Transfer roller bias - Normal paper - 2C
33
Transfer roller bias - Normal paper - 3C
34
*
Transfer roller bias - Normal paper - 4C (Letter)
Service
Tables
SM 4-63 A172/A199
