14. SERVICE TABLES
14.1 DIP SWITCHES AND SWITCH
Modes
DPS101 DPS102 SW
Function
12341234101
Motor Tests
(Speed Adj.)
1101
1000—
Feed-in motor (M2) activates (High
Speed)
1001—
Feed-in motor (M2) activates (Low
Speed)
0100—
Belt drive motor (M3) activates
0010—
Feed-out motor (M4) activates
(High Speed)
0011—
Feed-out motor (M4) activates
(Low Speed)
Friction Belt
Free Run
1110
1000
↓
Friction belt motor (M1) activates
(Reverse)
1001
↓
Friction belt motor (M1) activates
(Forward)
100—
↓
Push SW101 to feed the page in.
Push it again to feed the sheet out.
MC, SOL
Tests
0011
1000—
Stopper solenoid (SOL2) activates
0100—
Not used
0010—
Feed-in clutch (CL1) activates
0001—
Inverter solenoid (SOL1) activates
Original
Feed
Tests
0101
0000
↓
Feeds the original in and out
(thick / one-sided)
0001
↓
Feeds the original in and out
(thin / one-sided)
1000
↓
Feeds the original in and out
(thick / two-sided)
1001
↓
Feeds the original in and out
(thin / two-sided)
0010
↓
Feeds the original in and out
(low speed / thick / one-sided)
0011
↓
Feeds the original in and out
(low speed / thin / one-sided)
1010
↓
Feeds the original in and out
(low speed / thick / two-sided)
1011
↓
Feeds the original in and out
(low speed / thin / two-sided)
0100
↓
Feeds the original in and out
(pasted original mode)
1110
↓
Feeds the original in and out
(combine original mode)
0: OFF 1: ON ↓ : Push
A172/A199 7-26 SM
