8. OTHERS
8.1 OPTICS COOLING FAN FILTER REPLACEMENT
1. Remove the top left cover [A] (1 screw).
2. Remove the filter securing bracket [B] (1 screw).
3. Remove the optics cooling fan filter [C].
[B]
[C]
[A]
A172/A199 5-26 SM
