Publication 2094-UM001A-EN-P — September 2006
Configure and Startup the Kinetix 6000 Drive System 125
Configure the Logix
SERCOS interface Module
This procedure assumes that you have wired your Kinetix 6000 system
and have configured the baud rate and optical power switches.
For greater detail on the RSLogix 5000 software as it applies to
configuring the ControlLogix, CompactLogix, or SoftLogix SERCOS
modules, refer to Additional Resources on page 10.
Configure the Logix Controller
Follow these steps to configure the Logix controller.
1. Apply power to your Logix chassis/personal computer containing
the SERCOS interface module and open your RSLogix 5000
software.
2. From the File menu, choose New.
The New Controller dialog opens.
3. Configure the new controller.
a. Select controller type.
b. Select RSLogix 5000 software revision.
c. Name the file.
d. Select the Logix chassis size.
e. Select the Logix processor slot.
4. Click OK.
5. From the Edit menu, choose Controller Properties.
The Controller Properties dialog opens.
IMPORTANT
In order for the Kinetix 6000 drive to communicate with the
SERCOS interface module (indicated by the three LED indicators
on the module going solid green), your RSLogix 5000 software
must be revision 11.0 or later.
