170 Specifications and Dimensions
Power Specifications
This section contains power specifications for your Kinetix 6000
system components.
Integrated Axis Module (converter) Power Specifications
IAM (230V) Power Specifications
Specification
Description
2094-AC05-MP5-S 2094-AC05-M01-S 2094-AC09-M02-S 2094-AC16-M03-S 2094-AC32-M05-S
AC input voltage
195...264V rms
three-phase (230V nom)
AC input frequency 47...63 Hz
Main ac input current
(1)
Nom (rms)
Max inrush (0-pk)
10 A
20 A
19 A
33 A
36 A
65 A
71 A
120 A
DC input voltage (common bus follower) 275...375V dc
DC input current (common bus follower) 10 A 19 A 36 A 71 A
Control power ac input voltage
95...264V rms
single-phase (230V nom)
Control power ac input current
Nom (@ 220/230V ac) rms
Nom (@ 110/115V ac) rms
Max inrush (0-pk)
3 A
6 A
20 A
3 A
6 A
83 A
(2)
Nominal bus output voltage 325V dc
Line loss ride through 20 ms
Continuous output current
to bus (A
dc
)
10 A 19 A 36 A 71 A
Intermittent output current
to bus (A
dc
)
(3)
20 A 38 A 72 A 142 A
Bus overvoltage 425V dc
Bus undervoltage 138V dc
Internal shunt
Continuous power
Peak power
N/A
N/A
50 W
8000 W
200 W
5600 W
200 W
5600 W
Internal shunt resistor N/A 20 Ω 28.75 Ω 28.75 Ω
Shunt on N/A 405V dc
Shunt off N/A 375V dc
Continuous power output to bus 3 kW 6 kW 11.3 kW 22.5 kW
Peak power output 6 kW 12 kW 22.6 kW 45.0 kW
Efficiency 95%
Converter inductance N/A 150 μH 75 μH
Converter capacitance 270 μF 540 μF 1320 μF 1980 μF
(1)
All 2094-xCxx integrated axis modules are limited to 2 contactor cycles per minute (with up to 4 axis modules), or 1 contactor cycle per minute (with 5 to 8 axis modules).
(2)
Maximum inrush duration is less than 1/2 line cycle.
(3)
Intermittent output current duration equals 250 ms.
