Connecting the Kinetix 6000 Drive System 85
Wiring the VAC LINE (IPL) Connector
Line Interface Module (IPL connector)
VAC LINE (IPL) Connector
2094-AL09, -ALxxS, -BLxxS, and -XL75S-Cx
VAC LINE (IPL) Connector
2094-BL02
L3
L2
L1
1 2 3 4
Line Interface Module, Top View
(2094-XL75S-Cx is shown)
Three-phase Supply IPL Pin Signal
Recommended
Wire Size
mm
2
(AWG)
Strip Length
mm (in.)
Torque Value
Nm (lb-in)
L1 4 L1
2.5-25
(14-4)
16.0
(0.63)
2.7
(24)
L2 3 L2
L3 2 L3
1
Three-phase Supply IPL Pin Signal
Recommended
Wire Size
mm
2
(AWG)
Strip Length
mm (in.)
Torque Value
Nm (lb-in)
L1 1 L1
4.0
(12)
10.0
(0.38)
1.5 - 1.8
(13.2 - 15.9)
L2 2 L2
L3 3 L3
4
