Publication 2094-UM001A-EN-P — September 2006
Configure and Startup the Kinetix 6000 Drive System 131
11. Select the Bus Regulator Catalog Number or other as appropriate
for your actual hardware configuration.
12. Click OK.
13. Repeat steps 1...9 for each 2094-xMxx axis module.
If your IAM is
And your hardware configuration includes this shunt
option
Then select
Configured as an IAM or
Leader IAM (common bus)
(1)
Internal shunts only Internal or <none>
Bulletin 2094 (rail mounted) shunt module 2094-BSP2
Bulletin 1394 passive shunt module (connected to the
2094-BSP2)
1394-SRxxxx
Bulletin 1336 active shunt module Internal or <none>
Configured as a Follower IAM
(2)
N/A. Shunts are disabled on Follower IAM CommonBus Follow
(1)
Drive will not accept Internal, <none>, 2094-BSP2, or 1394-SRxxxx selection if dc bus voltage is present without having three-phase power applied.
(2)
Drive will not accept CommonBus Follow selection if three-phase power is applied.
ATTENTION
To avoid damage to your Bulletin 1394 external shunt
module, verify that the proper 230V or 460V fuse is
installed prior to applying power.
Refer to Circuit Breaker/Fuse Specifications on page 177,
for more information.
IMPORTANT
When configured to use the Bulletin 1394 or 2094 shunt
modules, the IAM bus regulator capacity attribute displays
the shunt module or passive shunt module utilization
instead of the IAM internal shunt resistor utilization.
IMPORTANT
DC common bus applications must calculate Total Bus
Capacitance and Additional Bus Capacitance and set the
Add Bus Cap parameter (x:x:x599) using DriveExplorer
software.
Refer to the Appendix D beginning on page 231, for more
information.
